NEW ORIGINAL TESCOM 54-2000 Series Pressure Regulator Hydraulic 54-2061T26 54-206 26-2000 54-2800

  • NEW ORIGINAL TESCOM 54-2000 Series Pressure Regulator Hydraulic 54-2061T26 54-206 26-2000 54-2800
  • NEW ORIGINAL TESCOM 54-2000 Series Pressure Regulator Hydraulic 54-2061T26 54-206 26-2000 54-2800
  • NEW ORIGINAL TESCOM 54-2000 Series Pressure Regulator Hydraulic 54-2061T26 54-206 26-2000 54-2800
  • NEW ORIGINAL TESCOM 54-2000 Series Pressure Regulator Hydraulic 54-2061T26 54-206 26-2000 54-2800
  • NEW ORIGINAL TESCOM 54-2000 Series Pressure Regulator Hydraulic 54-2061T26 54-206 26-2000 54-2800
Place of Origin Singapore
Brand Name TESCOM
Certification -
Model Number 54-2061T26
Minimum Order Quantity 1
Price USD980/PC
Packaging Details Original
Delivery Time 2weeks
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 1000

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Warranty 1 Year Model Number 54-2061T26
Maximum Inlet Pressure 10,000 Psig / 690 Bar Load Type Spring
Weight 5.3 Lbs / 2.4 Kg
Highlight

54-2061T26 Pressure Regulator

,

54-2000 Series Pressure Regulator

,

Hydraulic Pressure Regulator
Leave a Message
Product Description



Product Description

54-2000 Series pressure reducing regulator is suitable for 10,000 psig / 690 bar inlet and outlet hydraulic applications. Segregated and captured vent allows for convenient downstream pressure reduction adjustments. Hardened Stainless Steel seat and stem provide excellent wear resistance in harsh applications. Ideal for use in wellhead control panels, subsea valve actuations, Hydraulic Power Units (HPU) and component testing.

Specifications


Maximum Inlet Pressure
10,000 psig / 690 bar
Outlet Pressure Ranges
5-500, 5-800, 10-1500, 15-2500, 25-4000, 50-6000, 200-10,000 psig
0.35-34.5, 0.35-55.2, 0.69-103, 1.0-172, 1.7-276, 3.4-414, 13.8-690 bar
Material
Body: 316 Stainless Steel
Main Valve, Vent Seat, Poppets: 17-4 Stainless Steel
O-Rings: Viton-A®, Buna-N, Ethylene Propylene, Kalrez®
Back-up Rings: PTFE
Remaining Parts
300 Series Stainless Steel and 17-4 Stainless Steel
Ambient Operating Temperature2
-15°F to 165°F / -26°C to 74°C
2 For extended temperatures from -40°F to 400°F / -40°C to 204°C, consult TESCOM.
Port Size & Type
1/4, 3/8, 1/2
SAE, NPTF, MS33649, High Pressure, Medium Pressure
External Vent Port (1/4): SAE, NPTF, MS33649
Flow Capacity
Main Valve: Cv = 0.06
Vent Valve: Cv = 0.08NEW ORIGINAL TESCOM 54-2000 Series Pressure Regulator Hydraulic 54-2061T26 54-206 26-2000 54-2800 0NEW ORIGINAL TESCOM 54-2000 Series Pressure Regulator Hydraulic 54-2061T26 54-206 26-2000 54-2800 1NEW ORIGINAL TESCOM 54-2000 Series Pressure Regulator Hydraulic 54-2061T26 54-206 26-2000 54-2800 2NEW ORIGINAL TESCOM 54-2000 Series Pressure Regulator Hydraulic 54-2061T26 54-206 26-2000 54-2800 3
