XS3 Programming Logic Controller XS3-26T4 16MB 800MHz CPU

  • XS3 Programming Logic Controller XS3-26T4 16MB 800MHz CPU
  • XS3 Programming Logic Controller XS3-26T4 16MB 800MHz CPU
  • XS3 Programming Logic Controller XS3-26T4 16MB 800MHz CPU
  • XS3 Programming Logic Controller XS3-26T4 16MB 800MHz CPU
Place of Origin CHINA
Brand Name xinje
Certification CCC ISO
Model Number XS3-26T4
Minimum Order Quantity 1
Price ($550-$800)/PC
Packaging Details Carton (standard original package)
Delivery Time 14 Work days
Payment Terms L/C, T/T, Western Union
Supply Ability 1000/PC/MONTH

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Isolation Above DC 500V 2MΩ Anti-noise Noise Voltage 1000Vp-p 1us Pulse 1 Minute
Ambient Temperature 0℃~60℃ Ambient Humidity 5%~95% (no Condensation)
Main CPU 800MHz CAM Control EtherCAT Bus, 32 Axes
High Light

XS3 programming logic controller

,

programming logic controller XS3-26T4

,

800MHz CPU PLC programming controller
You can tick the products you need and communicate with us in the message board.
RS232 1 port, connect IP modification tool and other devices
RS485 2 ports, MODBUS, connect HMI and other devices
RJ45 port 1 LAN1: Ethernet communication, support program download and monitoring
RJ45 port 2 LAN2: EtherCAT real-time bus master station
Leave a Message
RS232 1 port, connect IP modification tool and other devices
Product Description

XS3 series programming logic controller XS3-26T4 The program capacity is 16MB Isolation Above DC 500V 2MΩ

XS3 series PLC

Medium sized PLC, with powerful function, strong applicability and larger storage space. The program capacity is 16MB and the speed is 5-6 times that of XG1.

Product features

The new high-performance medium-sized PLC has more powerful functions, stronger applicability and larger storage space

Based on Codesys programming platform, fully support PLC open programming specification

Many standard function libraries can be referenced to develop proprietary function blocks and instruction libraries

Support EhterCAT motion control, EtherCAT remote IO and Ehternet communication

32 channels of electronic cam function. Online download

Up to 16 XG series expansion modules can be expanded

It supports 4 channels of 200kHz pulse output and 4 channels of high-speed counting (up to 200kHz).

Model

Input points

(DC24V)

Output points

(R, T)
AC power supply DC power supply
  Relay output Transistor output Relay and transistor mixed output Relay output Transistor output Relay and transistor mixed output
NPN - - - - XS3-26T4 - 18 8

XS3 Programming Logic Controller XS3-26T4 16MB 800MHz CPU 0XS3 Programming Logic Controller XS3-26T4 16MB 800MHz CPU 1

General Specifications

Item Specification
Isolation Above DC 500V 2MΩ
Anti-noise Noise voltage 1000Vp-p 1us pulse 1 minute
Air No corrosive, flammable gas
Ambient temperature 0℃~60℃
Ambient humidity

5%~95% (no condensation)


Installation It is directly installed on the XG-EB series guide rail
Ground (FG) The third type grounding (do not grounding with strong power system)





Functional Specifications

Item Specification
CPU I/O Total points 26
Input points 18
Output points 8
Max I/O points 1050
High speed positioning Normal pulse output 4 channels, max 200K
High speed input Single phase/AB mode 4 channels, max 200K
Input mode Differential input
Expansion ability Right expansion module 16
Interrupt External interrupt 10
Communication RS232 1 port, connect IP modification tool and other devices
RS485 2 ports, MODBUS, connect HMI and other devices
RJ45 port 1 LAN1: Ethernet communication, support program download and monitoring
RJ45 port 2 LAN2: EtherCAT real-time bus master station
Bus motion control EtherCAT bus, 32 axes
CAM control EtherCAT bus, 32 axes
Programming mode ST, SFC, FBD, CFC, LD, IL
Main CPU 800MHz
User program capacity 16M
Data capacity 8M



Function configuration table:

Series USB port RS232 port RS485 Ethernet EtherCAT Expansion module High speed counting channel

Pulse output channel

(T/RT)

 External interruption
Increase mode AB phase
XS3-26T4 × 1 2 √ √ 16 4 4 4 10

Note: All the models have RTC function.
