Dwyer 477B Hand Held Digital Manometer Large LCD For Air

Place of Origin USA
Brand Name Dwyer
Certification CCC CE ISO
Model Number 477B
Minimum Order Quantity 1
Price $460-$588/PCS
Packaging Details 100% original package
Delivery Time 14work days
Payment Terms L/C, D/P, T/T, Western Union
Supply Ability 1000Piece/Pieces per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Warranty 1 Years Medium Air And Compatible Gases
Type Differential Pressure Gauges Weight 289 G
Accuracy ±0.1% Temperature Resistance -17.8 ~ 60 ℃
Pressure Limits See Chart
High Light

Dwyer 477B hand held digital manometer


Hand held digital manometer large LCD


Large LCD Dwyer digital manometer

You can tick the products you need and communicate with us in the message board.
Model 477B-2
Model 477B-2
Model 477B-2
Model 477B-2
Model 477B-2
Model 477B-2
Leave a Message
Model 477B-2
Product Description


Precise Air Pressure Measurement, ±0.1% F.S. Accuracy

The Series 477B Handheld Digital Manometers are versatile, hand-held, battery operated manometers available in several basic ranges from 0-20 in w.c. up to 100 psi. All models measure either positive, negative or differential pressures with ±0.10% of full scale accuracy. You can select from up to seven common English and metric pressure units so conversions are not necessary. A memory function allows storage of up to 40 readings for later recall and a backlight provides auxiliary lighting for hard-to-see locations. Also standard are a hold feature plus both visual and audible overpressure alarms.

NIST CALIBRATION available in Product Configurator.

Model Description
477B-1 Handheld digital manometer, 0 to 20" w.c. (0 to 4.982 kPa)
477B-2 Handheld digital manometer, 0 to 40" w.c. (0 to 9.96 kPa)
477B-3 Handheld digital manometer, 0 to 200" w.c. (0 to 49.82 kPa)
477B-4 Handheld digital manometer, 0 to 10 psi (0 to 68.95 kPa)
477B-5 Handheld digital manometer, 0 to 30 psi (0 to 206.9 kPa)
477B-6 Handheld digital manometer, 0 to 50 psi (0 to 344.7 kPa)
477B-7 Handheld digital manometer, 0 to 100 psi (0 to 689.5 kPa)
Air and compatible gases.
Wetted Parts:
Consult factory.
±0.10% of full scale from 60 to 78F° (15.6 to 25.6°C); ±1% of full scale from 32 to 60 and 78 to 104°F (0 to 15 .6 and 25.6 to 40°C).
Pressure Hysteresis:
±0.1% of full scale.
Pressure Limits:
See chart on catalog page.
Temperature Limits:
0 to 140°F (-17.8 to 60°C).
Storage Temperature Limits:
-4 to 176°F (-20 to 80°C).
4-digit LCD (.425" H x .234" W digits).
See chart on catalog page.
Power Requirements:
9 volt alkaline battery. Battery included but not connected.
Two barbed connections for use with 1/8" (3.18 mm) or 3/16" (4.76 mm) I.D. tubing for 477B-1, 477B-2, 477B-3, 477B-4 and 477B-5 only. Two compression fittings for use with 1/8" (3.18 mm) I.D. x 1/4" (6.35 mm) O.D. tubing for 477B-6 and 477B-7 only.
10.2 oz. (289 g).
Agency Approvals:
Dwyer 477B Hand Held Digital Manometer Large LCD For Air 0
Dwyer 477B Hand Held Digital Manometer Large LCD For Air 1Dwyer 477B Hand Held Digital Manometer Large LCD For Air 2
