Top Plunger Head Limit Switch Metal DPDT 2NC/2NO GLA Series Honeywell GLAA20C
| Place of Origin | china |
|---|---|
| Brand Name | Honeywell |
| Certification | CE |
| Model Number | GLAA20C |
| Minimum Order Quantity | 1 |
| Price | USD$260 |
| Packaging Details | carton |
| Delivery Time | 3-4weeks |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 500pc |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Actuator Type | Roller | Contact Form | 2 CO |
|---|---|---|---|
| Current Rating | 10 A | Head Type | Top Plunger Head |
| Highlight | Metal DPDT Limit Switch,2NC/2NO Limit Switch,Honeywell GLAA20C Limit Switch |
||
Product Description
Product Specifications
Product Attribute
Attribute Value
Search
Actuator Type
Roller
Contact Form
2 CO
Current Rating
10 A
Family Name
GLS Family
Head Type
Top Plunger Head
IP Rating
IP67
Mounting Hole Size
0.117 in
Number of Poles
2
Number of Positions
2
Operating Temperature
-25 to 85 °C
Series
Standards
UL Listed, CSA Certified, CE Marked
Termination
Screw
Type
Limit
Voltage Rating
600 V
Honeywell GLA Series — MICRO SWITCH Global Limit Switches:
Honeywell’s MICRO SWITCH™ GLA Limit Switch Series is designed to global EN50041 standards and well suited for worldwide applications. The modular design (heads/actuators, bodies, and contact blocks) of the limit switch allows for rapid response to meet customer applications. The rugged die-cast metal housing of the switch is ideal for indoor and outdoor applications where a degree of IP or NEMA enclosure sealing is required. Normally closed snap-action contacts and normally closed slow-action contacts are positive opening.
Features:
- Designed to EN50041 standard, 30 mm x 60 mm mounting
- Available as a standard body or plug-in body with same footprint
- Wide range of actuator heads and levers
- Side rotary switches factory set for CW and CCW actuation; field adjustable for CW only or CCW only
- Certified for global applications; UL/CSA (Americas/Canada), CE (Europe), CCC (Asia-Pacific)
- Conforms to IEC/EN 60947-5-1, EN45545-2 (GLA/GLF Series)
- Sealed to IP67 and NEMA/UL 1, 4, 12, and 13
- Operating temperatures as low as -40 degC to 85 degC [-40 degF to 185 degF]
- Multiple connectivity options to meet most applications: four different threaded conduits, micro-change connectors, minichange connectors, Deutsch style 4-pin connector
- One or two LED indicators available in switch body
- Single pole double throw, two pole single throw contact blocks (1NC/1NO, 2NC, 2NO) are galvanically (electrically) isolated (Zb) and designed with bifurcated contacts
- Two pole double throw contact block (2NC/2NO) has each pole galvanically (electrically) isolated (Zb)
- Normally closed contacts are positive opening , except center neutral style
- Contact blocks are available as snap action or slow action
- Analog output available with side rotary actuator
- Mechanical life up to 15 million operations
Applications: - Aerial lifts, boom lifts
- Automotive assembly lines and machining centers
- Agriculture equipment
- Conveyors
- Doors and apertures
- Material handling
- Machine tools
- Railroad locomotives and railroad signaling equipment
- Transportation hubs
- Valves
