IFM - IG0233 IGA2008-ABOA/BS-201-A Inductive Proximity Switch M18 Metal SN 8MM NF, N/O, 20 TO 250 V AC/DC, BS CONNEC

  • IFM - IG0233 IGA2008-ABOA/BS-201-A Inductive Proximity Switch M18 Metal SN 8MM NF, N/O, 20 TO 250 V AC/DC, BS CONNEC
  • IFM - IG0233 IGA2008-ABOA/BS-201-A Inductive Proximity Switch M18 Metal SN 8MM NF, N/O, 20 TO 250 V AC/DC, BS CONNEC
  • IFM - IG0233 IGA2008-ABOA/BS-201-A Inductive Proximity Switch M18 Metal SN 8MM NF, N/O, 20 TO 250 V AC/DC, BS CONNEC
  • IFM - IG0233 IGA2008-ABOA/BS-201-A Inductive Proximity Switch M18 Metal SN 8MM NF, N/O, 20 TO 250 V AC/DC, BS CONNEC
Place of Origin china
Brand Name IFM
Certification CE
Model Number IG0233
Minimum Order Quantity 1
Price USD$80
Packaging Details carton
Delivery Time 6-8weeks
Payment Terms L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability 500pc

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Sensing Range [mm] 8 Dimensions [mm] M18 X 1 / L = 81
Protection Class II Reverse Polarity Protection No
Highlight

Metal Inductive Proximity Switch

,

M18 Inductive Proximity Switch
Leave a Message
Product Description
Product characteristics
Output function normally open
Sensing range [mm] 8
Housing Threaded type
Dimensions [mm] M18 x 1 / L = 81
Electrical data
Operating voltage [V] 20...250 AC/DC
Protection class II
Reverse polarity protection no
Outputs
Output function normally open
Max. voltage drop switching output DC [V] 6
Max. voltage drop switching output AC [V] 6.5
Minimum load current [mA] 5
Max. leakage current [mA] 2.5 (250 V AC) / 1.3 (110 V AC) / 0.8 (24 V DC)
Permanent current rating of switching output AC [mA] 250; (350 (...50 °C))
Permanent current rating of switching output DC [mA] 100
Short-time current rating of switching output [mA] 2200; (20 ms / 0,5 Hz)
Switching frequency AC [Hz] 25
Switching frequency DC [Hz] 100
Short-circuit proof no
Overload protection no
Monitoring range
Sensing range [mm] 8
Real sensing range Sr [mm] 8 ± 10 %
Operating distance [mm] 0...6.5
Accuracy / deviations
Correction factor steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminum: 0.3 / copper: 0.2
Hysteresis [% of Sr] 1...15
Switch-point drift [% of Sr] -10...10
Operating conditions
Ambient temperature [°C] -25...80
Protection IP 67
Tests / approvals
EMC
EN 60947-5-2
EN 55011 class B
MTTF [years] 604
Mechanical data
Weight [g] 59.9
Housing Threaded type
Mounting non-flush mountable
Dimensions [mm] M18 x 1 / L = 81
Thread designation M18 x 1
Material brass white bronze coated; PBT natural
Displays / operating elements
Display
Switching status 1 x LED, yellow
Electrical connection
Required protection miniature fuse to IEC60127-2 sheet 1; ≤ 2 A; fast acting
Accessories
Items supplied
lock nuts: 2
Remarks
Remarks
Recommendation: check the unit for reliable function after a short circuit.
Pack quantity 1 pcs.
