High Pressure Float Level Switch Low Set Point Pressure Switch Sensor 1/8" NPT

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xMore Information Switch Application | High Press/Low SP J205 (1-800psig) | Set Point Pressure Range | 4 To 100 |
---|---|---|---|
Maximum Amperage And Voltage | 5 Amp 250 VAC Silver | Electrical Interface | TB - 1/4" Terminal Blades |
Fitting | 1/8" NPT Male | Wetted Materials | Stainless & Buna |
Highlight | High Pressure Float Level Switch,Float Level Switch Low Set Point,pressure switch sensor 1/8" NPT |
Type | water level float switch | |
---|---|---|
Type | float level switch | |
Type | cable float level switch | |
Type | water level controller | |
Type | explosion proof float switch | |
Type | high temperature float switch |
J205G High Pressure/Low Set Point Pressure Switch
The J205G High Pressure Low Set Point Pressure Switches are among our most versatile offering, affording the end user an extensive operating environment and a wide range of set point optionality.
- Set Point Range: 0.80 to 800 PSIG
- Max System Pressure: 5,000 PSIG
- Temperature range: -65°F to +225°F (-54°C to +107°C)
-
Switch Application High Press/Low SP J205 (1-800psig) Is OEM Replacement Part? No Stock In Stock Wetted Materials Stainless & Buna Corrosive Media No Wet/Dry/Submerged Standard (Dry Use) Additional Options Many Options Are Available. If It's Not Here, Call Us. Standard Fitting Size 1/8"NPT Shipping Weight Ounces 7 Oz
-
The Whitman Controls J205G High Pressure Low Set Point Pressure Switches are among our most versatile offering, affording the end user an extensive operating environment and a wide range of set point optionality. These switches can be exposed to high pressure without compromising integrity or switch functionality. Uses include gas bottle change switches and oil or water supply control. They are frequently used in pump and reservoir applications. The internals are stainless steel with a diaphragm o-ring that is available in numerous compounds.
Key Features:
- Overpressure feature, allowing the switch to be subject to high pressure without compromising integrity
- Set point options: Factory set, field adjustable, or a combination
- Extensive operating temperature range
- Wide range of electrical interfaces available
- SPDT or SPST availability
- Wide range of set point optionality
-
Specifications:
- Set point range: 0.80 to 800 PSIG
- Max System pressure: 5,000 PSIG
- Temperature range: -65°F to +225°F (-54°C to +107°C)
- Amps: 5 Amps Max
- Sensor Element: Diaphragm
- Weight: 4.0 oz (varies slightly with electrical interface selection)
- Wetted Parts:
Diaphragm: 316 Stainless Steel
Seal: Loctite #271
Body / Fitting: 303 Stainless Steel
O-Ring: Buna N Standard (Special material available upon request)
Standard Thread: ⅛-27 NPT male -
