10 Bar Norgren Air Solenoid Valve 24V DC 220V AC Solenoid Air Control Valve
| Place of Origin | UK |
|---|---|
| Brand Name | Norgren |
| Certification | CCC CE ISO |
| Model Number | SXE9573-A76-00/19J |
| Minimum Order Quantity | 1 |
| Price | $100-$150/PC |
| Packaging Details | 100% original package |
| Delivery Time | 30 work days |
| Payment Terms | L/C, D/P, T/T, Western Union |
| Supply Ability | 1000Piece/Pieces per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Warranty | 1 Year | Actuation | Sol/Air Spring |
|---|---|---|---|
| Operating Pressure | 1 ... 10 Bar | Operating Temperature | -15 ... 80 °C |
| Product Name | Solenoid Valve | Marketing Type | New Product 2021 |
| Weight (KG) | 0.5 | Single Package Size | 15X10X5 Cm |
| High Light | Norgren Air Solenoid Valve,Air Solenoid Valve 24V DC,220V AC Solenoid Air Control Valve |
||
Product Description
SXE9573-A76-00/19J coil voltage 220VAC British Norgren (IMI norgren) solenoid valve technical parameters: belong to ISO1# valve, flow 1230l/min, working pressure 1.8-10bar, valve body weight 0.33kg, with Norgren common 22mm coil , Voltage 220VAC! Application industry: cement production line equipment control!
British IMI NORGREN (IMI NORGREN) ISO&STAR series solenoid pilot valve and pneumatic control valve bottom plate technology advantages: special coating metal sealing valve core valve sleeve, trouble-free long life operation, ISO#1 and ISO#2 valves with integrated flow Regulating valve, standard type with manual control low-power solenoid coil, abundant base plate and accessories!
British IMI NORGREN (IMI NORGREN) ISO&STAR series solenoid pilot valve and pneumatic control valve bottom plate technical parameters: 1) media filtered lubricated or non-lubricated compressed air; 2) working pressure withstand 16bar; 3) flow ISO#1 is 1230l/ min, ISO#2 is 2450l/min, ISO#3 is 4400l/min; 4) Ambient temperature-electric control valve is -15 to 50 degrees Celsius, air control valve is -15 to 80 degrees Celsius; 5) material valve body-cast Aluminum, valve core and valve sleeve with special Teflon coated hard alumina treated aluminum, sealant-NBR!
SXE9573-A75-00 British Norgren IMI norgren solenoid valve technical parameters: ISO1# valve, flow rate 1230l/min, working pressure 1.8-10bar, valve body weight 0.33kg single electric control, with 1 coil, spool is made in Switzerland The life of the metal spool and spool can reach more than 100 million times, assembled in Germany! Application industry: Bottle blowing machine equipment in the food and beverage industry, cement production line equipment control!
Norgren ISO&STAR series solenoid pilot valve and pneumatic control valve bottom plate technology advantages: special coating metal sealing valve core valve sleeve, trouble-free long-life operation, ISO#1 and ISO#2 valves with integral flow control valve, standard type With manual control of low-power electromagnetic coils, abundant base plates and accessories!
Norgren ISO&STAR series solenoid pilot valve and pneumatic control valve bottom plate technical parameters: 1) media filtered lubricated or non-lubricated compressed air; 2) working pressure withstand pressure of 16bar; 3) flow ISO#1 is 1230l/min, ISO#2 2450l/min, ISO#3 is 4400l/min; 4) Ambient temperature-electric control valve is -15 to 50 degrees Celsius, air control valve is -15 to 80 degrees Celsius; 5) Material valve body-cast aluminum, valve core and Valve sleeve with special Teflon coated hard alumina treated aluminum, sealant-NBR!
