Fluke 1630-2 FC Ground Clamp Maximum Voltage to Earth Ground 1000 V Battery Type AA Alkaline IEC/EN LR6 x4

  • Fluke 1630-2 FC Ground Clamp Maximum Voltage to Earth Ground 1000 V Battery Type AA Alkaline IEC/EN LR6 x4
  • Fluke 1630-2 FC Ground Clamp Maximum Voltage to Earth Ground 1000 V Battery Type AA Alkaline IEC/EN LR6 x4
  • Fluke 1630-2 FC Ground Clamp Maximum Voltage to Earth Ground 1000 V Battery Type AA Alkaline IEC/EN LR6 x4
  • Fluke 1630-2 FC Ground Clamp Maximum Voltage to Earth Ground 1000 V Battery Type AA Alkaline IEC/EN LR6 x4
Place of Origin CHINA
Brand Name Fluke
Certification CE
Model Number 1630-2 FC
Minimum Order Quantity 1
Price 2100/PC
Packaging Details Paper box
Delivery Time 1WEEK
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 500

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Maximum Voltage To Earth Ground 1000 V Battery Type AA Alkaline IEC/EN LR6 (x4)
Battery Life More Than 15 Hours* Frequency Range 40 Hz To 1 KHz
Highlight

1630-2 FC Ground Clamp

,

AA Alkaline Ground Clamp

,

1000 V Ground Clamp
Leave a Message
Product Description
Electrical Specifications
Maximum voltage to earth ground 1000 V
Battery type AA alkaline IEC/EN LR6 (x4)
Battery life More than 15 hours*
* In Ground Resistance measurement mode, with backlight turned off, and RF mode turned off
Frequency range 40 Hz to 1 kHz
Ingress protection IEC/EN 60529: IP30 with jaw closed
LCD Digital reading 9999 counts
Refresh rate 4 per second
Operating temperature -10 °C to + 50 °C
Storage temperature -20 °C to + 60 °C
Operating humidity Non condensing (<10 °C) (< 50 °F)
≤90% RH (at 10 °C to 30 °C [50 °F to 86 °F])
≤75% RH (at 30 °C to 40 °C [86 °F to 104 °F])
≤45% RH (at 40 °C to 50 °C [104 °F to 122 °F])
(Non condensing)
Operating altitude 2000 m (6561 feet)
Storage altitude 12 000 m (39,370 feet)
Reference temperature 23 °C ±5 °C (73 °F ±9 °F)
Temperature coefficient 0.15% x (specified accuracy)/ °C (<18 °C or >28 °C [<64.4 °F or >82.4 °F])
Overload indication OL
Data logging capacity Minimum of 32,760 measurements
Data logging interval 1 second to 59 minutes and 59 seconds
Display reading specification with standard loop resistance
Input (Ω) Minimum Maximum
0.474 0.417 0.531
0.5 0.443 0.558
10 9.55 10.45
100 96 104
Safety
General IEC/EN 61010-1: Pollution Degree 2 IEC/EN 61557-1
Measurement IEC/EN 61010-2-032: CAT IV 600 V / CAT III 1000 V
Current clamp for leakage current measurements IEC/EN 61557-13: Class 2, ≤30 A/m
