2-wire Output Type NJ1 5-8-N-Y18812 Inductive Sensor With Special Adjustment And 1.5 Mm Rated Operating Distance

  • 2-wire Output Type NJ1 5-8-N-Y18812 Inductive Sensor With Special Adjustment And 1.5 Mm Rated Operating Distance
  • 2-wire Output Type NJ1 5-8-N-Y18812 Inductive Sensor With Special Adjustment And 1.5 Mm Rated Operating Distance
  • 2-wire Output Type NJ1 5-8-N-Y18812 Inductive Sensor With Special Adjustment And 1.5 Mm Rated Operating Distance
  • 2-wire Output Type NJ1 5-8-N-Y18812 Inductive Sensor With Special Adjustment And 1.5 Mm Rated Operating Distance
Place of Origin china
Brand Name P+F
Certification CE
Model Number NJ1,5-8-N-Y18812
Minimum Order Quantity 1
Price USD$1100
Packaging Details carton
Delivery Time 1-2weeks
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 500pcs

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Output Type 2-wire Rated Operating Distance 1.5 Mm
Installation Flush
Highlight

2-wire Inductive Sensor

,

NJ1 Inductive Sensor

,

1.5 mm Inductive Sensor
Leave a Message
Product Description
General specifications
Switching function Normally closed (NC)
Output type NAMUR
Rated operating distance 1.5 mm
Installation flush
Assured operating distance 0 ... 0.97 mm
Reduction factor rAl 0.4
Reduction factor rCu 0.3
Reduction factor r304 0.85
Output type 2-wire
Nominal ratings
Nominal voltage 8 V
Switching frequency 0 ... 2000 Hz
Hysteresis 0.1 mm
Current consumption
  Measuring plate not detected min. 2.5 mA
  Measuring plate detected ≤ 1.2 mA
Functional safety related parameters
MTTFd 11467 a
Mission Time (TM) 20 a
Diagnostic Coverage (DC) 0 %
Compliance with standards and directives
Standard conformity
  Standards EN IEC 60947-5-2
