Endress+Hauser FTC260-BA4J1 Capacitance level switch Minicap, Alu IP66, M20, ATEX II 1/2D, EN10226 R1, PPS
| Place of Origin | china |
|---|---|
| Brand Name | Endress+Hauser |
| Certification | CE |
| Model Number | FTC260-BA4J1 |
| Minimum Order Quantity | 1 |
| Price | USD$440 |
| Packaging Details | carton |
| Delivery Time | 6-8weeks |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 500pc |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Sensor Length | 140 Mm (5.51") | Process Connection | R1" NPT1" |
|---|---|---|---|
| Options | Aluminium Housing | Process Temperature | -40°C ...+120°C |
| Highlight | Alu Capacitance level switch,PPS Capacitance level switch |
||
Product Description
-
Characteristic / Application
Compact rod probe with build-up compensation
easy start up -
Specialities
FDA-listed material
-
Supply / Communication
10,8 ... 45V DC, DC-PNP 3-wire
20 ... 253V AC, or
20 ... 55V DC, Relay output -
Ambient temperature
-40°C...+70°C
(-40°F...+158°F) -
Process temperature
-40°C ...+120°C
(-40°F ...+248°F) -
Process pressure / max. overpressure limit
-1 ... 25 bar
(-14.5 ... 360 psi) -
Main wetted parts
PPS = Polyphenylene sulphide
(glass fibre content approx. 40%) -
Process connection
R1"
NPT1" -
Sensor length
140 mm (5.51")
-
Communication
PNP transistor output
Relay output (potential-free
change-over contact / SPDT) -
Certificates / Approvals
ATEX , IEC Ex, FM, CSA, NEPSI, UK Ex
-
Options
Aluminium Housing
-
Application limits
Solids, grain size max. 30 mm (1.2"),
DK min 1,6
Flexural strength 1400 N (at probe tip)
