Dwyer Series 645 Wet / Wet Differential Pressure Transmitter 645-4

  • Dwyer Series 645 Wet / Wet Differential Pressure Transmitter 645-4
  • Dwyer Series 645 Wet / Wet Differential Pressure Transmitter 645-4
  • Dwyer Series 645 Wet / Wet Differential Pressure Transmitter 645-4
  • Dwyer Series 645 Wet / Wet Differential Pressure Transmitter 645-4
Place of Origin USA
Brand Name Dwyer
Certification CCC,CE
Model Number 645-4
Minimum Order Quantity 1
Price USD$150/PCS
Packaging Details carton
Delivery Time 5-8 WORK DAYS
Payment Terms L/C, D/A, D/P, T/T
Supply Ability 1000

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Service Compatible Gases Or Liquids On Both Pressure And Reference Sides. Wetted Materials 17-4 PH Stainless Steel, 300 Series Stainless Steel, Fluoroelastomer And Silicone O-rings And Bleed Screw Seals.
Accuracy ±0.25% FS (RSS) Output Signal 4 To 20 MA, 2-wire
Loop Resistance 0 To 1000Ω. Weight 0.4g
High Light

Differential Pressure Transmitter 645-4

,

645 Differential Pressure Transmitter

,

Wet Wet Differential Pressure Transmitter
You can tick the products you need and communicate with us in the message board.
Product Type Pressure transmitter
Power Requirements 11 to 30 VDC
Process Connection 1/4″-18 female NPT.
Response Time 30 to 50 ms.
Leave a Message
Product Type Pressure transmitter
Product Description

Dwyer Series 645 Wet/Wet Differential Pressure Transmitter 645-x





Product Description

±0.25% Accuracy, Quick Response, 2-Wire Design

Series 645 Wet/Wet Differential Pressure Transmitters are designed for use with compatible gases and liquids which can be applied to both the pressure and reference ports. Quick response capacitance sensor delivers a 4 to 20 mA output signal proportional to differential pressure with ±.25% accuracy. The Series 645 transmitters are ideal for process control, filter condition monitoring, refrigeration equipment, pump speed control, HVAC equipment, and liquid level measurement. For ease of installation and maintenance, order optional 3-valve manifold assembly. Bleed ports allow for total elimination of air in the line and pressure cavities.



Models

Model Description
645-0 Wet/wet differential pressure transmitter, range 0-1 psid.
645-0-3V Wet/wet differential pressure transmitter with 3-valve manifold assembly, range 0-1 psid.
645-1 Wet/wet differential pressure transmitter, range 0-2 psid.
645-1-3V Wet/wet differential pressure transmitter with 3-valve manifold assembly, range 0-2 psid.
645-10 Wet/wet differential pressure transmitter, range ±0.5 psid.
645-10-3V Wet/wet differential pressure transmitter with 3-valve manifold assembly, range ±0.5 psid.
645-11 Wet/wet differential pressure transmitter, range ±1 psid.
645-11-3V Wet/wet differential pressure transmitter with 3-valve manifold assembly, range ±1 psid.
645-12 Wet/wet differential pressure transmitter, range ±2.5 psid.
645-12-3V Wet/wet differential pressure transmitter with 3-valve manifold assembly, range ±2.5 psid.
645-13 Wet/wet differential pressure transmitter, range ±5 psid.
645-13-3V Wet/wet differential pressure transmitter with 3-valve manifold assembly, range ±5 psid.
645-14 Wet/wet differential pressure transmitter, range ±10 psid.
645-14-3V Wet/wet differential pressure transmitter with 3-valve manifold assembly, range ±10 psid.
645-15 Wet/wet differential pressure transmitter, range ±25 psid.
645-15-3V Wet/wet differential pressure transmitter with 3-valve manifold assembly, range ±25 psid.
645-16 Wet/wet differential pressure transmitter, range ±50 psid.
645-16-3V Wet/wet differential pressure transmitter with 3-valve manifold assembly, range ±50 psid.
645-2 Wet/wet differential pressure transmitter, range 0-5 psid.
645-2-3V Wet/wet differential pressure transmitter with 3-valve manifold assembly, range 0-5 psid.
645-3 Wet/wet differential pressure transmitter, range 0-10 psid.
645-3-3V Wet/wet differential pressure transmitter with 3-valve manifold assembly, range 0-10 psid.
645-4 Wet/wet differential pressure transmitter, range 0-25 psid.
645-4-3V Wet/wet differential pressure transmitter with 3-valve manifold assembly, range 0-25 psid.
645-5 Wet/wet differential pressure transmitter, range 0-50 psid.
645-5-3V Wet/wet differential pressure transmitter with 3-valve manifold assembly, range 0-50 psid.
645-6 Wet/wet differential pressure transmitter, range 0-100 psid.
645-6-3V Wet/wet differential pressure transmitter with 3-valve manifold assembly, range 0-100 psid.
