xCategory | Fixed Gas Detector | Type | Stand-alone Gas Detector |
---|---|---|---|
Target Gas | NMP (N-methylpyrrodidone) | Detection Principle | Catalytic Combustion |
Detection Range | 0-100 %LEL | Sampling Method | Diffusion |
Highlight | Fixed Gas Monitor Analyzers,SD-2500 Fixed Gas Monitor,NMP Furnace Gas Detector |
Type of alarm | Gas alarm, Trouble alarm | |
---|---|---|
Explosion proof | Flameproof enclosure | |
Approvals | TEX, TIIS, CE | |
Power source | DC24V | |
Dimensions | 148(W) x 161(H) x 88(D) mm | |
Weight | Approx 4.6kg | |
Operating temperature (Sensor) | 0 to +200 ℃ | |
Medium temperature | 0...160°C | |
Insertion depth | 250mm |
Riken Keiki SD-2500 Fixed Gas Monitor For Inside Furnace GD-A2400 SD-2600 SD-2700 Gas Detectors/Analyzers
Description
The Riken Keiki SD-2500 safety monitor for inside furnace is a gas detector for the high-boiling solvent in exhaust duct and furnace. The SD-2500 features a long sensor head (250mm in length), operating in high temperature 0 to 160℃, flameproof enclosure, and smooth operation with the control key.
Riken Keiki SD-2500 Specification
- Category Fixed gas detector
- Type Stand-alone gas detector
- Target gas NMP (N-methylpyrrodidone)
- Detection principle Catalytic combustion
- Detection range 0-100 %LEL
- Sampling method Diffusion
- Type of alarm Gas alarm, Trouble alarm
- Explosion proof Flameproof enclosure
- Approvals TEX, TIIS, CE
- Power source DC24V
- Dimensions & Weight Main body: 148(W) x 161(H) x 88(D) mm
- Insert part: φ34 x 250 mmApprox 4.6kg
- Operating temperature & Humidity Main body: 0 to 50oC
- Insert part: 0 to 160oC
item
|
value
|
Warranty
|
1 year
|
Type
|
Gas Monitor
|
Customized support
|
OEM, ODM
|
Place of Origin
|
Japan
|
Brand Name
|
Riken Keiki
|
Model Number
|
SD-2500
|
Target gas
|
NMP (N-methylpyrrodidone)
|
Detection principle
|
Catalytic combustion
|
Insertion depth
|
250mm
|
Type of alarm
|
Gas alarm, Trouble alarm
|
Explosion proof
|
Flameproof enclosure
|
Power source
|
DC24V
|
Dimension
|
148(W) x 161(H) x 88(D) mm
|
Weight
|
4.6 kg
|
Medium temperature
|
0...160°C
|
Operating temperature (Sensor)
|
0 to +200 ℃
|
Riken Keiki
