Digital Differential Pressure Gauge Wall Mounting Magnesense MS-111-LCD

  • Digital Differential Pressure Gauge Wall Mounting Magnesense MS-111-LCD
  • Digital Differential Pressure Gauge Wall Mounting Magnesense MS-111-LCD
  • Digital Differential Pressure Gauge Wall Mounting Magnesense MS-111-LCD
  • Digital Differential Pressure Gauge Wall Mounting Magnesense MS-111-LCD
  • Digital Differential Pressure Gauge Wall Mounting Magnesense MS-111-LCD
  • Digital Differential Pressure Gauge Wall Mounting Magnesense MS-111-LCD
Place of Origin USA
Brand Name Dwyer
Certification CCC.CE
Model Number MS-111
Minimum Order Quantity 1
Price usd 90 piece/pieces
Packaging Details carton
Delivery Time 3-5 work days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 1000

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Brand Dwyer Model MS-111
Temperature Effect 20 To 120°F Mounting Wall Mounting
Range High & Low Application Industries
High Light

Wall Mounting Differential Hydraulic Pressure Gauge

,

MS-111-LCD Differential Pressure Transmitter

,

Digital Differential Transmission Pressure Gauge
You can tick the products you need and communicate with us in the message board.
Warranty 1 year
Customized support OEM, ODM
Accuracy ±1% F.S. at 70°F.
Type Differential Pressure Gauges
Leave a Message
Warranty 1 year
Product Description

Dwyer Differential Pressure Transmitter Magnesense MS-111 MS-021 Series Digital differential pressure transmitter



Functional Specifications

  • Service: Air and non-combustible compatible gases
  • Stability: ±1% F.S./year
  • Temperature Limits: 0 to 150°F (-18 to 66°C)
  • Pressure Limits: 1 psi maximum, operation; 10 psi, burst
  • Output Signals: 4 to 20 mA (2-wire); 0 to 5 V, 0 to 10 V (3-wire)
  • Response Time: Field adjustable 0.5 to 15 sec. time constant. Provides a 95% response time of 1.5 to 45 seconds
  • Zero & Span Adjustments: Digital push button
  • Loop Resistance: Current Output: 0-1250 max. Voltage Output: min. load resistance 1 k
  • Current Consumption: 40 mA max
  • Display (optional): 4 digit LCD
  • Electrical Entry: 1/2" NPS Thread. Accessory: Cable Gland for 5 to 10 mm diameter cable
  • Process Connection: 3/16" (5 mm) ID tubing. Maximum OD 9 mm
  • Enclosure Rating: NEMA 4X (IP66)
  • Mounting Orientation: Diaphragm in vertical position

PRODUCT APPLICATIONS

  • Building pressure monitoring
  • Duct pressure monitoring
  • Fan velocity measurement
  • Zone differential pressure monitoring
  • Filter condition monitoring

Product Parameter

Brand Dwyer
Type Differential Pressure Gauges
Application Industries
Model MS-111-LCD
Mounting Wall mounting
Output 4-20mA
Customized support OEM, ODM
Warranty 1 year



Digital Differential Pressure Gauge Wall Mounting Magnesense MS-111-LCD 0

Digital Differential Pressure Gauge Wall Mounting Magnesense MS-111-LCD 1

Digital Differential Pressure Gauge Wall Mounting Magnesense MS-111-LCD 2

Digital Differential Pressure Gauge Wall Mounting Magnesense MS-111-LCD 3

Digital Differential Pressure Gauge Wall Mounting Magnesense MS-111-LCD 4

General Specifications

  • Power Requirements: 10 to 35 VDC (2-wire)
  • 17 to 36 VDC or isolated 21.6 to 33 VAC (3-wire)
  • Weight: 8.0 oz (230 g)

Magnesense must be installed on a plane that is perpendicular to the horizontal plane. The pressure connection hole and wire connection pipe must be oriented downward. Fix it stably on the plane with three screws, not too tight. If you choose other installation Angle, will cause a large loss of accuracy.



  • Adjustable Digital Dampening smooths out unstable pressure fluctuations common in air flow applications.



  • Field Selectable Air Velocity Mode for fan and blower applications. Unit provides square root output that accurately tracks fpm or m/s flow rate. No need for a smart programmable indicator or PLC to convert pressure to air flow. Reduces components and installation time lowering overall costs.

MS-111-LCD

Differential pressure transmitter, 4-20 mA output, selectable range 1", 2", 5" w.c. (250, 500, 1250 Pa), wall mount, with LCD.

MS-121-LCD

Differential pressure transmitter, 4-20 mA output, selectable range 0.1", 0.25", 0.5" w.c. (25, 50, 100 Pa), wall mount, with LCD.

MS-021-LCD   MS-122-LCD  MS-131-LCD   MS-141-LCD   MS-151-LCD
