Aluminum 3051 Pressure Transmitter FF Protocal Up To 20000 PSIG

Place of Origin CHINA
Brand Name Emerson
Certification CCC
Model Number 3051
Minimum Order Quantity 1
Price Discussible
Packaging Details Carton (standard original package)
Delivery Time 30 Day(s)
Payment Terms L/C, D/A, T/T, , Western Union,
Supply Ability 1000/PC/Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Aluminum Accuracy Performance Up To 0.04%
Type Differential Pressure Transmitter Total Performance ±0.15%
Protocal Hart Or FF Output 4-20mA
Housing Material Aluminum Or SST Warranty 1 Year
High Light

aluminum 3051 pressure transmitter

,

3051 pressure transmitter FF Protocal

,

20000 PSIG differential Pressure transmitter

Leave a Message
Product Description

3051 pressure transmitter with 4-20ma ,transmitter with high quality and good service



3051C smart pressure transmitter combines advanced technology with the versatile Coplanar ™ process connection to create a new standard in pressure measurement technology. Even under the most demanding conditions, the performance specifications of the 3051C smart pressure transmitter provide unmatched long-term stability and reliability.



3051C smart pressure transmitter is capable of differential, gage, or absolute pressure measurement. Utilizing advanced capacitance sensor technology (piezoresistive sensors for absolute pressure models) the 3051C smart pressure transmitter is accurate up to ±0.04% resulting in total operating performance, the true measure of "real-world" transmitter performance, of ±0.15%. Additionally, the 3051C smart pressure transmitter has an installed five-year stability of ±0.125% demonstrating the ability to maintain performance over a five year period under the most demanding process conditions. The high accuracy and stability of the 3051C equates to reduced variability, lower operating and maintenancecosts, and improved plant safety.



Specifications
Warranty Up to 5-year limited warranty
Rangedown Up to 150:1
Communication Protocol 4-20 mA HART, WirelessHART, FOUNDATION fieldbus, Profibus, 1-5 V Low Power HART
Measurement Range Up to 20000 psig (1378,95 bar) Gage, Up to 20000 psia (1378,95 bar) Absolute
Process Wetted Material 316L SST, Alloy C-276
Diagnostics Basic Diagnostics, Loop Integrity
Certifications/Approvals SIL 2/3 certified to IEC 61508 by an independent 3rd party, NSF, NACE, hazardous location, see full specs for complete list of certifications

Aluminum 3051 Pressure Transmitter FF Protocal Up To 20000 PSIG 0



Confidently measure pressure and level with the Rosemount 3051 In-Line Pressure Transmitter. Engineered for 10-year installed stability and 0.04% of span accuracy, this industry-leading pressure transmitter provides you with the information necessary to run, control and monitor processes. The Rosemount 3051 includes features that meet your pressure measurement needs, such as a wide rangedown and Power Advisory diagnostics and is suitable for safety installations



Aluminum 3051 Pressure Transmitter FF Protocal Up To 20000 PSIG 1



Features
Over 10 million Rosemount 3051 devices installed globally, providing reliable pressure readings in harsh environments
In-line gage and absolute pressure measurements support up to 20,000 psi (1378,95 bar) for pressure and level solutions
10-year installed stability and 150:1 rangedown produce reliable measurements and wide application flexibility
Supports common protocols for integration in many host environments across many industries
Wide range of manifolds and remote seals are available – factory-assembled and leak-tested for easy installation
Local Operator Interface (LOI) enables quick commissioning and provides easy access to process and device information
SIL 2/3 certified to IEC 61508 (via 3rd party) and prior-use certificate of FMEDA data for safety installations
Loop Integrity diagnostics detect electrical loop issues for reduced downtime
