AC Single Drives ABB Inverter Power Converter ACS800 0.55 - 5600 Kw

Place of Origin Switzerland
Brand Name ABB
Certification CE
Model Number ACS800
Minimum Order Quantity 1
Price USD$580/PC
Packaging Details Carton
Delivery Time 5-8 work days
Payment Terms D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 500

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Warranty 1 Year Type AC Drive
Control Mode VFD INVERTER Rated Power 0.55 To 5600 KW
Nominal Voltage 380V Power Phase Number 3 Phase
Product Name Frequency Converter Frequency 50/60HZ
High Light

ABB Inverter Power Converter


AC Single Drives Inverter Power Converter


Inverter Frequency Converter ACS800

Leave a Message
Product Description

Low Voltage AC Drives ABB ACS800 Single Drives 0.55 To 5600 Kw

ABB Inverter Power Converter ACS800-01




AC Single Drives ABB Inverter Power Converter ACS800 0.55 - 5600 Kw 0



ABB industrial drives

ABB industrial drives are designed for industrial applications, and especially for applications in process industries such as the pulp & paper, metals, mining, cement, power, chemical, and oil & gas. ABB industrial drives are available both as complete AC drives and as modules to meet the requirements of the users, OEMs and system integrators. These drives are highly flexible AC drives that can be configured to meet the precise needs of industrial applications, and hence orderbased configuration is an integral part of the offering. The complete drives and drive modules cover a wide range of powers and voltages, including industrial voltages up to 690 V. ABB industrial drives come with a wide range of builtin options. A key feature of these drives is programmability, which makes adaptation to different applications easy.


Industrial design

ABB industrial drives are designed with current ratings to be used in industrial environment for applications requiring high overloadability. The heart of the drive is DTC, direct torque control, that provides high performance and significant benefits: e.g. accurate static and dynamic speed and torque control, high starting torque and long motor cables. Builtin drive options make the installation work fast and easy. The robust enclosures and cabinets, with a wide range of enclosure classes, as well as power terminals, are designed for harsh environments.


One of the most significant design criteria of ABB industrial drives has been the long lifetime. Wearing parts such as fans and capacitors have been selected accordingly. This means - together with extensive protection features - excellent reliability in the demanding industrial market.


Single drives

The single drive configuration contains a rectifier, DC link and an inverter in one single AC drive unit.

The single drives are complete AC drives that can be installed without any additional cabinet or enclosure. The single drives are available as wall-mounted, free-standing and cabinet-built constructions. The protection degree of the single drives is at least IP21, and higher protection degrees are available as an option.


Type designation

This is the unique reference number that clearly identifies your drive by construction, power rating voltage and selected options. By type designation you can specify your drives from the wide range of available options, customer specific ones are added to the type designation using the corresponding + code.


Functional safety

The ABB functional safety solution complies with the requirements of the new European Union machinery directive 2006/42/EC. This directive is associated with standards like IEC 62061 (Safety Integrity Level) and ISO 13849-1 (Performance Level), which require both a documented and proven safety performance and lifecycle approach to safety. Safe torque-off (STO) is a certified solution offering SIL2 and PL d (Cat.2) safety levels.


ABB drives can be provided, as an option, with the safe torque-off function. Safe torque-off (STO) can be used for the prevention of unexpected startup and represents a cost-effective and certified solution for basic safety. Other safety functions for cabinet-built drives include Safe Stop 1 (SS1) and Safely-Limited Speed (SLS), which can be used to achieve SIL2 or PL d (Cat.2) safety levels.




Place of Origin
Brand Name
Model Number
1 Year
AC drive
Control Mode
Rated Power
0.55 to 5600 kW
Nominal Voltage
power phase number
3 Phase
Product Name
Frequency Converter
Used condition
Pump, Machine ,Crane,Motor
Mounting Type
High quality low price
100% new and original
