Siemens Echomax XPS Ultrasonic Level Transducer Echomax XPS-10 XPS-15 XPS-30 Ultrasonic Sensor 7ML1115-1CA30 EchoMax XRS-5

EchoMax XPS transducers use ultrasonic technology to measure level in a wide range of liquids and solids.

Siemens EchoMax XPS-10 Ultrasonic Level Transducer, high frequency, continuous, non-contact, 32.80 ft. (10m), for liquid and solid applications. Mounting thread and facing: 1″ NPT ((Taper), ANSI/ASME B1.20.1), cable length: 98.43 ft. (30 m) flange, flush mount: no flange approvals: ATEX II 2GD, FM Class I Div 2/SAA Class 1 Zone 1 .

Mounting Recommendations:

• Special handling precautions must be taken to protect the face of the transducer from any damage
• Mount the transducer so that it is above the maximum material level by at least the blanking value (0.3m for XPS 10 F and 0.45m for XPS 15 F)
• On liquid applications, the transducer must be mounted so that the axis of transmission is perpendicular to the liquid surface
• On solids applications, a Milltronics Easy Aimer should be used to facilitate aiming of the transducer
• Do not over-tighten mounting. Hand tightening of the mounting hardware is sufficient
• Secure installation by connecting a safety chain from the transducer to a structural member
• Consider the optional temperature sensor when mounting the transducer

Benefits

• Integral temperature compensation
• Low ringing effect reduces blanking distance
• Optional foam facing for dusty applications
• Self-cleaning and low-maintenance
• Chemically resistant • Hermetically sealed

Application

• XPS transducers can be fully immersed, are resistant to steam and corrosive chemicals, and can be installed without flanges.
• The XPS series offers versions for various measuring ranges up to 30 m (100 ft) and up to a max. temperature of 95 °C (203 °F).
• During operation, the EchoMax transducers emit acoustic pulses in a narrow beam. The level monitor measures the propagation time between pulse emission and its reflection (echo) to calculate the distance.

Specification

item	value
Model Number	XPS-10 7ML1115-
Type	Ultrasonic Transducer
Place of Origin	China
Brand Name	Siemens
Output	44 kHz
Description	EchoMax XPS-10 Ultrasonic level transducer
Product family	EchoMax XPS
Weight	0.8 kg (1.8 lb)
Measuring Range	0.3 to 10 m / 1 to 33 ft
Beam Angle	12 °
Ambient Temperature	-40 to 95 ℃ / -40 to 203 ℉
Cable Connection	2 wire twisted pair
Pressure Range	8 bar / 120 psi
Color	Blue
Degree of protection	IP66/68
Process connection	1" NPT or 1" BSPT
