NBN15-30GM40-Z0 Inductive proximity switch 15mm Two wire

Place of Origin Germany
Brand Name Pepperl+Fuchs
Certification CCC.CE
Model Number NBN15-30GM40-Z0
Minimum Order Quantity 10
Price usd35 piece/pieces
Packaging Details carton
Delivery Time 10-15 work days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 100

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Brand Name Pepperl+Fuchs Model NBN15-30GM40-Z0
Output Type Two-wire Rated Operating Distance 15 Mm
Switching Function Normally Open (NO) Output Polarity DC
Connection Type Output Polarity
High Light

NBN15-30GM40-Z0 Inductive proximity switch


Inductive proximity switch 15mm


inductive type proximity sensor 15mm

Leave a Message
Product Description

New and original Pepperl+Fuchs Inductive sensor NBN15-30GM40-Z0 Inductive proximity switch


Product Description

Using active shielding technology, Varikont inductance sensors ensure a large switching distance regardless of installation conditions and surrounding materials, thus simplifying the design of equipment and being economical and efficient!

Inductive safety sensors that conform to SIL 2/PL D standards have no blind spots for detection, so data transfer can be carried out without minimum distance between sensor and target. Learn more about optimized product portfolios for harsh environments.

Inductive proximity sensors are the products of most applications, which cover the fields of mechanical instruments and automation equipment requiring high-precision, non-contact detection of metal objects. Pepperl + Fuchs is a market for innovative, high quality inductive proximity sensors to meet the needs of automation and process control markets worldwide. We have many years of experience in this field, flexible work, customer oriented everywhere, according to the needs of different customers to provide unique solutions.



Brand name Pepperl+Fuchs
Model NBN15-30GM40-Z0
Operating voltage 5 ... 60 V
Switching frequency 0 ... 150 Hz
Hysteresis 1 ... 10 typ. 5 %
Voltage drop ≤ 5 V
Operating current 2 ... 100 mA
Switching status display Operating current
Connection type Cable PVC , 2 m
Ambient temperature -25 ... 70 °C (-13 ... 158°F)
Wire cross-section 0.34 mm2
Housing material Brass, nickel-plated
Abutting face PBT
Cable diameter 4.8 mm ± 0.2 mm
Protection IP67



NBN15-30GM40-Z0 Inductive proximity switch 15mm Two wire 0

NBN15-30GM40-Z0 Inductive proximity switch 15mm Two wire 1

NBN15-30GM40-Z0 Inductive proximity switch 15mm Two wire 2

It is recommended to ask the customer service about the weight and size, subject to the actual data replied by the customer service Due to SKU problem, the product price is different. Please ask customer service for specific price.
